PARAMETER | VALUE |
Operating Voltage | 12V - 240VAC/DC |
Operating Frequency | 50 / 60 Hz |
Operating Power | <4VA |
Operating Temperature | -20°C…..55°C |
Weight | <100Gr |
Time Range | On Delay Timer 0.1min - 100min |
Display | 2 LEDS |
Contact | 1NO+1NC |
5A/250VAC | |
Protection Class | IP20 |
Connection Type | Terminal Connection |
Cable Diameter | Max1.5mm² |
Mounting | DIN Rail Mounting |
Working Altitude | <2000 meter |
